Chassis Features

• Advanced electric power steering system gives the KingQuad 750AXi Power Steering lighter steering and even more responsive handling than ever
• Reduced effort from the Power Steering permits higher handlebars for increased rider comfort
• Polyethylene skid plates provide protection with minimal resistance over rocks and rough terrain. Durable plastic guards protect the front and rear half shafts
• Stylish bodywork features high-clearance fenders that offer great protection for the rider from flying debris. Refined panels simplify maintenance needs, such as oil level checks
• High traction 25-inch CARLISLE tires are mounted on lightweight, yet strong, aluminum wheels
• Independent double A-arm front suspension (7.1 inches of wheel travel) includes large diameter shock absorbers with 5-way spring preload adjustment
• Fully independent, A-arm/I-beam rear suspension with 7.9 inches of wheel travel includes large diameter shock absorbers with 5-way spring preload adjustment and large diameter rear sway-bar
• Dual hydraulic front disc brakes plus a sealed, multi-plate rear brake system. The rear brake’s clutch-type design provides high durability, reduced unsprung weight and low-maintenance
• High traction 25-inch CARLISLE tires are mounted on lightweight, yet strong, aluminum wheels
• Suzuki's plush T-shaped seat delivers rider mobility during spirited or difficult terrain riding

Engine Features

• High capacity aluminum radiator with large diameter, thermostatically controlled cooling fan provides stable engine operating temperature
• The powerful 722cc, DOHC, single-cylinder, liquid-cooled, four-stroke engine is tuned to deliver strong low-to-mid range torque as well as high-rpm power
• The cylinder and head are canted forward for a low center of gravity resulting in reduced engine height and lower seat height. High-mount air intake avoids water and debris
• The 4-valve cylinder head has large 36mm intake valves and straight ports for superb cylinder charging efficiency. A sportbike-derived chain-and-gear camshaft drive system creates a compact cylinder head
• A lightweight aluminum cylinder uses SCEM (Suzuki Composite Electrochemical Material) coating for excellent heat transfer and ring sealing resulting in superb combustion chamber efficiency
• The engine also features dual balancer shafts for smooth operation
• Advanced Suzuki Fuel Injection improves throttle response and fuel efficiency, while delivering power consistently across the full rev-range, and improves engine starting in all conditions
• High capacity aluminum radiator with large diameter, thermostatically controlled cooling fan provides stable engine operating temperature

Key Features

• Commanding fuel-injected engine runs clean and economical
• Advanced electric power steering delivers light and responsive steering
• Fender-mounted shifter controls the QuadmaticTM transmission
• Pushbutton 2WD, 4WD or 4WD full-lock drive mode selection
• Fully independent and adjustable suspension
• Ready for outdoor action with True Timber camouflaged bodywork

Special

• Minimum Operator Age: 16 Years Old

Transmission Features

• The QuadMatic™ CVT-type automatic transmission provides versatility and convenience with a fender-mounted gate-type shifter for high/low range selection. Its advanced engine-braking system minimizes free-wheeling with the throttle off and helps control the vehicle during steep descents
• A compact torque-sensing limited-slip front differential offers potent traction plus light steering. A differential-lock system provides serious four-wheel-drive traction
• Handlebar-mounted push-button controls permit easy selection between 2WD, 4WD and differential-lock 4WD. An override button on the left handlebar can be used to override the normal speed limiter when stuck in the mud

Utility / Convenience Features

• Full floorboards with integrated raised footpegs provide protection
• Dual 35W headlights (with high and low settings) are part of the distinctive KINGQUAD grille appearance. Bright tail light help make the ATV visible in dark conditions
• Standard tow hitch, ready to accept a No. 1 type ball, lets you take advantage of the ATV’s strong towing capacity
• Winch-ready mounts and wire conduit makes winch installation simple
• Instrumentation includes LCD readouts for speedometer, odometer, twin tripmeter, hour meter, clock, fuel level, driving range and drive mode. LED indicators for high, low, neutral, reverse and 2WD/4WD and differential-locked 4WD. LED cautions for fuel injection and engine temperature
• High-output, three-phase charging system feeds an 18-amp maintenance-free battery for abundant power for easy starting and accessory use. A sealed 12V accessory outlet is standard
• The large 4.6 gallon (17.5 L) fuel tank is positioned for a low center-of-gravity. It includes a vacuum-operated petcock and a ratchet-style filler cap (which prevents over tightening so it can be easily unscrewed for refilling)
• A large 2.8 liter water resistant front storage compartment includes an easy access screw-on cap
• The rugged steel-tube cargo racks have wrinkle paint finish for durability and scratch resistance
• 12-month limited warranty
